Ideal for both residential and commercial applications, it ensures uninterrupted power supply with advanced technology and robust build quality.
|
System Specificatoin
|
|
|
Battery Chemistry
|
LFP (LiFePO4)
|
|
Nominal Output Power
|
125KW
|
|
Battery Capacity
|
261.284kWh
|
|
Battery Nominal Voltage
|
832V
|
|
Operating DC Voltage Range
|
650V-949V
|
|
Recommended. Charging/
Discharging Current
|
157[1]
|
|
Fire Fighting System
|
1.Sensor Tube(Aerosol) 2.Water Fire Fighting System 3.Heat/Smoke/Gas sensor
|
|
Cell Cycle life
|
6000[2]
|
|
DOD
|
90%
|
|
Warranty
|
3 Years Product Warranty, 10 Years Battery Warranty
|
|
Conmmunication
|
|
|
Communication port
|
CAN, RS485, Ethernet
|
|
Communication protocol
|
ModbusRTU/TCP
|
|
Mechanical
|
|
|
Dimensions(W x D x H)
|
1000 x 1390 x 2430mm
|
|
Weight
|
2500kg
|
|
Cooling System
|
Liquid cooling
|
|
IP protection
|
IP55
|
|
Environmental
|
|
|
Reactive Humidty
|
0-95% (no condensing)
|
|
Operating Temperature Range
|
-20~55°C
|
|
Recommended Cell Temperature Range
|
Charge:0~55°C; Discharge:-20~55°C
|
|
Altitude
|
Temperature Rise: 8°C/h / 14.4°F/h |
| Certification |
2000m (>2000 derating)
|
|
Regulations
|
|
|
Certification
|
CELL
IEC 62619, UL1642, UL1973, UL9540A, UN38.3
PCS
CE-EMC, CE-LVD, South Africa NRS097, 50549-1 European general, 50549-2 European general, 50549-1 Netherlands, 50549-1 C10/11 Belgium, 50549-1 Greece, 50549-1 Sweden, 50549-1 Poland, England-G99, VDE-AR-N 4105:2018, GB/T 34120-2017
System
UN38.3, IEC62619, IEC63056, IEC62477, CE-EMC
|
[1] Charge and discharge current derating will occur outside 0°C and 45°C
[2] Under test conditions(20~35°C, 0.5P/0.5P, EOL70%)
